Description
Specification
| Model name | Indoor unit (IDU) | JTKJ35UV16W |
|---|---|---|
| Outdoor unit (ODU) | RKJ35UV16W | |
| Star Rating* | 5 Star | |
| Rated Power Supply | Phase/Frequency/Voltage | 1Ø/50Hz/230V |
| Power Supply Intake | Outdoor unit | |
| Rated Cooling Capacity Full/Half (min.-max.) | kW | 3.52/1.76 (1.09-4.0) |
| Btu/h | 12000/6000 (3720-13650) | |
| Cooling Capacity @ 46°C | % | 100% |
| Rated Power Consumption Full/Half (min.-max.) | W | 940/290 (196-1150) |
| Rated Annual Power Consumption | kWh | 523.54 |
| Rated ISEER | Wh/Wh | 5.2 |
| Voltage Range (Stabilizer Inside) | V | 130-285 |
| Operating Current | A | 4.3 |
Indoor unit (IDU)
| Panel Colour | White | |
|---|---|---|
| IDU Dimension (HxWxD) | mm | 298x800x229 |
| Package Dimension (HxWxD) | 375x895x325 | |
| IDU Net Weight (Gross Weight) | kg | 9.5 (12.5) |
| Airflow Rate | Feet3/min (cfm) | 420 |
| m3/min (cmm) | 11.9 | |
| Moisture Removal | I/hr (Litres/Hour) | 1 |
| Operation Sound H/MH/M/ML/L/SL | dBA | 40/38/36/33/30/27 |
Outdoor unit (ODU)
| ODU Dimension (HxWxD) | mm | 550x675x284 | |
|---|---|---|---|
| Package Dimension (HxWxD) | 620x825x400 | ||
| ODU Net Weight (Gross Weight) | kg | 24 (30) | |
| Compressor Type | Swing Compressor | ||
| Refrigerant | R-32 | ||
| Breaker size | A | 15 | |
| Piping length | Charge-Less | m | 10 |
| Max. Length | 15 | ||
| Max. Height | 12 | ||
| Piping Connection | Gas / Liquid | mm (Inch) | Ø9.5/Ø6.4 (3/8″/1/4″) |
| Operating Ambient Temperature Range | Cooling (Min-Max) | °C DB | 20-54 |
